瑞典ATLASCOPCO气动装配工具 |
|
油压脉冲拧紧扳手-手枪式 |
 |
EPPTS型号
ErgoPulse
PTS是一款可靠性高和功率强大的重型扭紧扳手，采用与PTX型号相同的断气式结构。由PTS系列型号增加顶部进气构成的HRF型拧紧扳手可实现顶部供气，这使得其能够在众多工位中轻松使用。所有PTS型拧紧扳手与其他ErgoPusle工具一样，均为无油润滑。
|
|
|
|
|
参数表 |
|
型号 |
螺栓尺寸mm |
驱动方头尺寸in |
扭矩范围nn |
空转速度r/min |
重量kg |
长度mm |
中心边缘距离mm |
带负载耗气量l/s |
推荐软管尺寸mm |
进气口尺寸in |
订货号 |
|
TRIM-RE |
|
EP5PTS12
HR42-RE |
M5-M6 |
1/4b |
6-12 |
5400c |
1.0 |
196 |
21 |
65 |
8 |
1/4 |
8431 0374 05 |
|
EP5PTS14
HR10-RE |
M5-M6 |
3/8 |
8-14 |
5400c |
1.0 |
191 |
21 |
65 |
8 |
1/4 |
8431 0374 00 |
|
EP6P1S20
HR42-RE |
M6 |
1/4b |
8-20 |
7300c |
1.0 |
196 |
21 |
7 |
8 |
1/4 |
8431 0374 15 |
|
EP6PTS22
HR10-RE |
M6 |
3/8 |
10-22 |
7300c |
1.0 |
191 |
21 |
7 |
8 |
1/4 |
8431 0374 20 |
|
TRIM-RE带平衡握把 |
|
EP7PTS30
HR42-RE |
M8 |
1/4b |
16-31 |
5700c |
1.4 |
175 |
26 |
8 |
10 |
1/4 |
8431 0374 35 |
|
EP7PTS35
HR10-RE |
M8 |
3/8 |
18-35 |
5700c |
1.4 |
176 |
26 |
8 |
10 |
1/4 |
8431 0374 40 |
|
EP8PTS40
HR42-RE |
M8 |
1/4b |
22-40 |
7300c |
1.4 |
175 |
26 |
9 |
10 |
1/4 |
8431 0374 55 |
|
EP8PTS55
HR10-RE |
M8-M10 |
3/8 |
30-55 |
7300c |
1.4 |
176 |
26 |
9 |
10 |
1/4 |
8431 0374 60 |
|
EP10PTS90
HR13-RE |
M10-M12 |
1/2 |
50-90 |
5200c |
1.8 |
193 |
29 |
11 |
10 |
1/4 |
8431 0374 80 |
|
EP12PTS150
HR13-RE |
M12-M14 |
1/2 |
85-150 |
4200c |
2.5 |
201 |
34 |
13 |
13 |
3/8 |
8431 0374 90 |
|
EP14PTS250
HR20-RE |
M12-M16 |
3/4 |
125-250 |
4200c |
3.3 |
216 |
37 |
20 |
13 |
3/8 |
8431 0374 95 |
|
EP18PTS410
HR20-RE |
M16-M20 |
3/4 |
225-410 |
3000c |
4.3 |
202 |
42 |
22 |
13 |
3/8 |
8431 0374 98 |
|
TRIM-RE顶端进气
|
|
EP7PTS35
HRF10-RE |
M8 |
3/8 |
18-35 |
5700c |
1.4 |
176 |
31 |
8 |
10 |
1/4 |
8431 0374 41 |
|
EP8PTS55
HRF10-RE |
M8-M10 |
3/8 |
30-55 |
7300c |
1.4 |
176 |
31 |
9 |
10 |
1/4 |
8431 0374 61 |
|
EP10PTS90
HRF13-RE |
M10-M12 |
1/2 |
50-90 |
5200c |
1.8 |
193 |
34 |
11 |
10 |
1/4 |
8431 0374 81 |
|
AutoTrim |
|
EP6PTS20
HR42-AT |
M6 |
1/4d |
8-20 |
6300d |
1.0 |
196 |
21 |
7 |
8 |
1/4 |
8431 0374 16 |
|
EP6PTS22
HR10-AT |
M6 |
3/8 |
10-22 |
6300d |
1.0 |
191 |
21 |
7 |
8 |
1/4 |
8431 0374 21 |
|
AutoTrim带平衡握把1 |
|
EP7PTS30
HR42-AT |
M8 |
1/4b |
16-31 |
5400d |
1.4 |
175 |
26 |
8 |
10 |
1/4 |
8431 0374 37 |
|
EP7PTS35
HR10-AT |
M8 |
3/8 |
18-35 |
5400d |
1.4 |
176 |
26 |
8 |
10 |
1/4 |
8431 0374 42 |
|
EP8PTS40
HR42-AT |
M8 |
1/4b |
22-40 |
6900d |
1.4 |
175 |
26 |
9 |
10 |
1/4 |
8431 0374 57 |
|
EP8PTS55
HR10-AT |
M8-10 |
3/8 |
30-55 |
6900d |
1.4 |
176 |
26 |
9 |
10 |
1/4 |
8431 0374 62 |
|
EP10PTS90
HR13-AT |
M10-12 |
1/2 |
50-90 |
4900d |
1.8 |
193 |
29 |
11 |
10 |
1/4 |
8431 0374 82 |
|
EP12PTS150
HR13-AT |
M12-M14 |
1/2 |
85-150 |
4100d |
2.5 |
201 |
34 |
13 |
13 |
3/8 |
8431 0374 92 |
|
EP14PTS250
HR20-AT |
M12-M16 |
3/4 |
125-250 |
3900d |
3.3 |
216 |
37 |
20 |
13 |
3/8 |
8431 0374 97 |
|
EP18PTS410
HR20-AT |
M16-M20 |
3/4 |
225-410 |
2900d |
4.3 |
202 |
42 |
22 |
13 |
3/8 |
8431 0374 99 |
|
|
